RJ21 ICC Male to Female Telco Cable Assembly Right Facing for Data Application

Short Description:

Plug in connector cable, polyvinyl chloride insulation over conductors, used to extend multiple voice or data circuits from patch panel or punch down block.


  • Cable/Connector: Custom
  • MOQ: 300 Pieces
  • Supply Ability: 10000 Pieces per day
  • Factory Cartificate : ISO9001/ UL/ IATF16949
  • Our Advantage : Cable Assembly, one stop solution for any custom project
  • Product Detail

    Product Tags

    01 product description
    10
    7
    5
    4
    3
    1

    Board-to-board and cable-to-board connections are inexpensive with Power Dynamics shielded and unshielded Centronic connectors. There are 14, 24, 36, and 50 contacts available. P.C.B., solder cup, and I.D.C. termination types are available. They can be utilized in a vast array of applications involving computer and data interfaces. All PDI Centronic connectors are UL-approved for safety. Rj21 To Rj11, Rj21 To Rj45

    Two rows of pins with 25 contacts each make up the Centronics IDC connector. Bail locks are used to secure this connector. The older SCSI-1 devices most frequently use the Centronics 50 pin connection (scanners, storage devices, etc.). In voice/data applications, a modest variation of the Centronics 50 connection is utilized. A Telco connector is the usual name for this version.

    02 Technical Specification
    11
    Shell steel Zinc plated,Tin ploted or Nickel plated steel for rj21 breakout cable
    Pin connect Phosphor bronze or brass gold plated
    Insulator  PBT & Glass-fibre rainforce UL-94-VO
    Current Rated  5 Amp
    Dielectric Strength 1000V for one minute
    Insulator Resistance  1000Mn MIN.(at 500V DC)
    Tempareture  -55℃~105℃
    03 Application
    1

    1, From cable to cable    2, Computer terminal    3, Telemetering   4, Test Equipment

    5, Printer   6,Telecom VDSL Equipment   7,Computer Accessories    8,Communication Devices
